SMAJ系列

東沃電子SMAJ系列瞬態電壓抑制二極管，型號齊全，免費提供測試、方案、樣品服務，同時可根據客戶的需求定制。
封裝形式：SMA/DO-214AC
脈沖功率：400 W
工作電壓：5.0 V-440.0 V
脈沖電流：0.56 A-41.67 A
響應時間：<1.0 PS

產品詳情

產品特性
? 玻璃鈍化芯片
? 在10/1000μ波形重復率（占空比）：0.01%下，峰值脈沖功率可達400w
? 低漏電流
? 單、雙向單元
? 優良的鉗位能力
? 快速的響應時間
? 通過無鉛認證，符合ROHS

機械參數
? 方法：模制塑料
? 環氧樹脂：UL 94V-0阻燃劑
? 引線：可焊性按MIL-STD-750，方法2026可焊
? 極性：除雙極性外有色帶的一端為陰極
? 安裝位置：任何


型號 圖片 封裝 VBR.MIN(V) VBR.MAX(V) IT(mA) IR(μA) VRWM(V) IPP(A) VC(V) 下載

SMAJ5.0A/SMAJ5.0CA

SMA/DO-214AC

6.40

7.00

10

800

5.0

43.48

9.2

SMAJ6.0A/SMAJ6.0CA

SMA/DO-214AC

6.67

7.37

10

800

6.0

38.83

10.3

SMAJ6.5A/SMAJ6.5CA

SMA/DO-214AC

7.22

7.98

10

500

6.5

35.71

11.2

SMAJ7.0A/SMAJ7.0CA

SMA/DO-214AC

7.78

8.60

10

200

7.0

33.33

12.0

SMAJ7.5A/SMAJ7.5CA

SMA/DO-214AC

8.33

9.21

1

100

7.5

31.01

12.9

SMAJ8.0A/SMAJ8.0CA

SMA/DO-214AC

8.89

9.83

1

50

8.0

29.41

13.6

SMAJ8.5A/SMAJ8.5CA

SMA/DO-214AC

9.44

10.40

1

10

8.5

27.78

14.4

SMAJ9.0A/SMAJ9.0CA

SMA/DO-214AC

10.00

11.10

1

5

9.0

25.97

15.4

SMAJ10A/SMAJ10CA

SMA/DO-214AC

11.10

12.30

1

5

10.0

23.53

17.0

SMAJ11A/SMAJ11CA

SMA/DO-214AC

12.20

13.50

1

1

11.0

21.98

18.2

SMAJ12A/SMAJ12CA

SMA/DO-214AC

13.30

14.70

1

1

12.0

20.10

19.9

SMAJ13A/SMAJ13CA

SMA/DO-214AC

14.40

15.90

1

1

13.0

18.60

21.5

SMAJ14A/SMAJ14CA

SMA/DO-214AC

15.60

17.20

1

1

14.0

17.24

23.2

SMAJ15A/SMAJ15CA

SMA/DO-214AC

16.70

18.50

1

1

15.0

16.39

24.4

SMAJ16A/SMAJ16CA

SMA/DO-214AC

17.80

19.70

1

1

16.0

15.38

26.0

SMAJ17A/SMAJ17CA

SMA/DO-214AC

18.90

20.90

1

1

17.0

14.49

27.6

SMAJ18A/SMAJ18CA

SMA/DO-214AC

20.00

22.10

1

1

18.0

13.70

29.2

SMAJ19A/SMAJ19CA

SMA/DO-214AC

21.10

23.30

1

1

19.0

13.00

30.8

SMAJ20A/SMAJ20CA

SMA/DO-214AC

22.20

24.50

1

1

20.0

12.35

32.4

SMAJ22A/SMAJ22CA

SMA/DO-214AC

24.40

26.90

1

1

22.0

11.27

35.5

SMAJ24A/SMAJ24CA

SMA/DO-214AC

26.70

29.50

1

1

24.0

10.28

38.9

SMAJ26A/SMAJ26CA

SMA/DO-214AC

28.90

31.90

1

1

26.0

9.50

42.1

SMAJ28A/SMAJ28CA

SMA/DO-214AC

31.10

34.40

1

1

28.0

8.81

45.4

SMAJ30A/SMAJ30CA

SMA/DO-214AC

33.30

36.80

1

1

30.0

8.26

48.4

SMAJ33A/SMAJ33CA

SMA/DO-214AC

36.70

40.60

1

1

33.0

7.50

53.3

SMAJ36A/SMAJ36CA

SMA/DO-214AC

40.00

44.20

1

1

36.0

6.88

58.1

SMAJ40A/SMAJ40CA

SMA/DO-214AC

44.40

49.10

1

1

40.0

6.20

64.5

SMAJ43A/SMAJ43CA

SMA/DO-214AC

47.80

52.80

1

1

43.0

5.76

69.4

SMAJ45A/SMAJ45CA

SMA/DO-214AC

50.00

55.30

1

1

45.0

5.50

72.7

SMAJ48A/SMAJ48CA

SMA/DO-214AC

53.30

58.90

1

1

48.0

5.17

77.4

SMAJ51A/SMAJ51CA

SMA/DO-214AC

56.70

62.70

1

1

51.0

4.85

82.4

SMAJ54A/SMAJ54CA

SMA/DO-214AC

60.00

66.30

1

1

54.0

4.59

87.1

SMAJ58A/SMAJ58CA

SMA/DO-214AC

64.40

71.20

1

1

58.0

4.27

93.6

SMAJ60A/SMAJ60CA

SMA/DO-214AC

66.70

73.70

1

1

60.0

4.13

96.8

SMAJ64A/SMAJ64CA

SMA/DO-214AC

71.10

78.60

1

1

64.0

3.88

103.0

SMAJ70A/SMAJ70CA

SMA/DO-214AC

77.80

86.00

1

1

70.0

3.54

113.0

SMAJ75A/SMAJ75CA

SMA/DO-214AC

83.30

92.10

1

1

75.0

3.31

121.0

SMAJ78A/SMAJ78CA

SMA/DO-214AC

86.70

95.80

1

1

78.0

3.17

126.0

SMAJ80A/SMAJ80CA

SMA/DO-214AC

88.80

97.60

1

1

80.0

3.09

129.6

SMAJ85A/SMAJ85CA

SMA/DO-214AC

94.40

104.00

1

1

85.0

2.92

137.0

SMAJ90A/SMAJ90CA

SMA/DO-214AC

100.00

111.00

1

1

90.0

2.74

146.0

SMAJ100A/SMAJ100CA

SMA/DO-214AC

111.00

123.00

1

1

100.0

2.47

162.0

SMAJ110A/SMAJ110CA

SMA/DO-214AC

122.00

135.00

1

1

110.0

2.26

177.0

SMAJ120A/SMAJ120CA

SMA/DO-214AC

133.00

147.00

1

1

120.0

2.07

193.0

SMAJ130A/SMAJ130CA

SMA/DO-214AC

144.00

159.00

1

1

130.0

1.91

209.0

SMAJ140A/SMAJ140CA

SMA/DO-214AC

155.00

171.00

1

1

140.0

1.76

226.8

SMAJ150A/SMAJ150CA

SMA/DO-214AC

167.00

185.00

1

1

150.0

1.65

243.0

SMAJ160A/SMAJ160CA

SMA/DO-214AC

178.00

197.00

1

1

160.0

1.54

259.0

SMAJ170A/SMAJ170CA

SMA/DO-214AC

189.00

209.00

1

1

170.0

1.45

275.0

SMAJ180A/SMAJ180CA

SMA/DO-214AC

200.00

220.00

1

1

180.0

1.37

291.6

SMAJ190A/SMAJ190CA

SMA/DO-214AC

211.00

232.00

1

1

190.0

1.30

307.8

SMAJ200A/SMAJ200CA

SMA/DO-214AC

224.00

247.00

1

1

200.0

1.23

324.0

SMAJ220A/SMAJ220CA

SMA/DO-214AC

246.00

272.00

1

1

220.0

1.12

356.0

SMAJ250A/SMAJ250CA

SMA/DO-214AC

279.00

309.00

1

1

250.0

0.99

405.0

SMAJ300A/SMAJ300CA

SMA/DO-214AC

335.00

371.00

1

1

300.0

0.82

486.0

SMAJ350A/SMAJ350CA

SMA/DO-214AC

391.00

432.00

1

1

350.0

0.71

567.0

SMAJ400A/SMAJ400CA

SMA/DO-214AC

447.00

494.00

1

1

400.0

0.62

648.0

SMAJ440A/SMAJ440CA

SMA/DO-214AC

492.00

543.00

1

1

440.0

0.56

713.0

SMAJ3.3A/SMAJ3.3CA

SMA/DO-214AC

4.30

5.30

10

200

3.3

54.80

7.3
